Technical Specification:
Size: DN50-DN200
Pressure: PN10/PN16
Design:DIN F4
Face to Face: DIN3202 F4
Flanges:EN1092-2 PN10/16
Hydraulic test: EN12266；ISO 5208
Seat Test:11/17.6bar
Shell Test:15/24bar
Technical Specification:
Size: DN50-DN600
Pressure: PN10/16
Design:BS5163
Face to Face: BS5163
Flanges:EN1092-2 PN10/16
Hydraulic test: ISO 5208
Seat Test:17.6bar Shell Test:24ba
Features：
Outside stem and yoke (OS&Y) Stem Seal with O-ring
Bolt bonnet, Full bore
Rubber encapsulated wedge, Brass Wedge Nut.
Fusion bonded epoxy coated inside and outside , blue RAL 5017 250 Micron thick
Working pressure :16Bar
working temperature from -10 to +80 ºC
Technical Specification:
Size: 2″- 24″
Pressure: Class150-Class1500
Material: WCB,LCB,LCC,WC6,WC9,C12,CF8,CF8M,CF3,CF3M
Technical Specification:
Size: DN80-DN2000
Pressure: BFV06-PTF
Design: DIN3202 F4/F16
Face to face: Series 13/14
Flange Drilling:EN1092-2 PN10/16
Mounting pad:ISO5211
Inspection and Test:API598
Seat Test: 17.6bar
Shell Test: 24bar
Technical Specification:
Size: DN50-DN300
Pressure:FOOT VALVE DN50-DN300
Face to Face:DIN2533 PN16
Flanges:EN1092-2 PN16
Hydraulic test:BS EN12266-1 CLASS A
Seat Test: 17.6bar
Shell Test: 24bar
Technical Specification:
Size: DN50-DN300
Pressure: PN10/16
Design:BS3464
Face to Face: BS3464
Flanges:BS4504 PN10/16;
BS10 Table D
Hydraulic test: ISO 5208
Seat Test:11/17.6bar
Shell Test:15/24bar
Features：
Bolted Bonnet Replaceable O-ring
Rubber encapsulated wedge, Brass Wedge Nut.
Fusion bonded epoxy coated inside and outside , blue RAL 5017 200 Micron thick Working pressure 250 PSI/17.2 Bar Non-Shock Cold
Technical Specification:
Size: 1/2″- 12″
Pressure: Class150-Class600
Material: WCB,LCB,CF8,CF8M
Operate: Level, Gear box, Electric actuator, Pneumatic
Technical Specification:
Size: DN350-DN800
Pressure:FOOT VALVE DN350-DN800
Face to Face:DIN2533 PN16
Flanges:EN1092-2 PN16
Hydraulic test:BS EN12266-1 CLASS A
Seat Test: 17.6bar
Shell Test: 24bar
Technical Specification:
Size: DN40-DN300
Pressure: PN10/16
Design:BS3464
Face to Face: BS3464
Flanges:BS4504 PN10/16;
BS10 Table D
Hydraulic test: ISO 5208
Seat Test:11/17.6bar
Shell Test:15/24bar
