PVC Socket Ends Non-rising Resilient Seat Gate Valve-791

PVC Socket Ends Non-rising Resilient Seat Gate Valve

Features：
Stem Seal with O-ring
Bolt bonnet, Full bore
Rubber encapsulated wedge, Brass Wedge Nut.
Fusion bonded epoxy coated inside and outside , blue RAL 5017 200 Micron thick Working pressure 250 PSI/17.2 Bar Non-Shock Cold

Inquire Now Add To Cart
share:
Product Details

Technical Specification：
Valve design according to DIN 3352 / SABS 664
Face to face dimensions according to DIN 3202 F5/ SABS 664
Socket Ends dimensions comply ISO 4422 、 ISO 4422.2
Hydraulic test according to ISO5208


Item No.Part NameSpecification
1BodyDuctile Iron EN- GJS- 500- 7
2WedgeDuctile Iron EN- GJS- 500- 7
3Wedge CoatingNBR /EPDM EN 681-1
4Wedge NutCopper Alloy
5StemStainless Steel X20 Cr13
6Bonnet GasketNBR /EPDM EN 681-1
7BonnetDuctile Iron EN- GJS- 500- 7
8O Ring Back SealingEPDM/NBR
9Stem CollarStainless Steel / Copper Alloy
10O-RingEPDM/NBR
11O-RingEPDM/NBR
12Stuffing NutCopper Alloy
13Dust GuardEPDM/NBR
14HandWheelDuctile Iron EN- GJS- 500- 7
15Stem CapDuctile Iron EN- GJS- 500- 7
Size
LL1HH1WW.T(kg )
PIPE DIA.F5SABS

DN50632503357725028018089.5
DN657527033580265295180911
DN8090280335843003302001015
DN100110300355883503802201418
DN125125325375914104402201722
DN125140325375914104402202028
DN150160350405944504802503338
DN2002004004501005505802805060
DN2002254004501005505802805565
DN2502504504501256506803207080
DN30031550050014071074036095110
